Handheld Storage Compatibility Guide
Valve Steam Deck (OLED & LCD)
The Steam Deck supports UHS-I MicroSD cards. While you can insert a faster UHS-II card, the Deck's slot is capped at UHS-I speeds (~100MB/s), so we recommend a high-quality A2-rated UHS-I card for the best value.
SSD Upgrade Note: Both LCD and OLED models require an M.2 2230 NVMe SSD. This is the "short" drive . Do not attempt to force a 2242 or 2280 drive unless you are performing advanced chassis modifications.
⚠️ Nintendo Switch 2 Requirement
The Nintendo Switch 2 utilizes the MicroSD Express standard. These cards use PCIe lanes to reach speeds up to 800MB/s, which is required for next-gen assets.
CRITICAL: Do NOT buy standard UHS-I or UHS-II cards for Switch 2 games. They lack the necessary PCIe interface pins. Next-gen games will not run on legacy storage speeds.
PC Handheld SSD Compatibility List
Modern Windows handhelds have shifted away from the small 2230 drives to larger, standard PC drives. Check your specific model below before buying:
| Device Model | SSD Size (Internal) | MicroSD Max Speed |
|---|---|---|
| ROG Ally X (2024) | M.2 2280 (Standard) | UHS-II (312MB/s) |
| Legion Go / Go Gen 2 | M.2 2242 / 2280 | UHS-II (312MB/s) |
| MSI Claw 8 AI+ | M.2 2280 (Standard) | UHS-II (312MB/s) |
| Steam Deck / OG Ally | M.2 2230 (Mini) | UHS-I (~100MB/s) |
| Ayaneo Kun / Next | M.2 2280 (Standard) | UHS-II (312MB/s) |
Retro Handhelds (Anbernic, Retroid, Miyoo)
Most Linux and Android handhelds (like the RG35XX or Miyoo Mini) use a dual-card setup:
- TF1 Slot (System): Usually 16GB-64GB. Holds the OS. Reliable cards (SanDisk/Samsung) are crucial here.
- TF2 Slot (Games): Supports up to 512GB/1TB. This is where your ROM library lives. Speed matters less here; focus on capacity.
Frequently Asked Questions
Can I put a 2280 SSD in my Steam Deck?
Technically yes, but it requires physical modification of the heat shield and chassis. We strongly recommend sticking to M.2 2230 drives for the original Steam Deck and OLED models to avoid overheating or structural damage.
Which MicroSD card is required for Nintendo Switch 2?
You MUST use a card with the MicroSD Express logo. Standard UHS-I cards (the ones used for Switch 1) do not support the PCIe data transfer required for Switch 2 games.
Does the ROG Ally X support standard PC SSDs?
Yes! The 2024 ROG Ally X was redesigned to fit a full-size M.2 2280 NVMe SSD, making upgrades much cheaper and easier than the original model (which used 2230).
